HJL DC Fast Charger 30 kW

HJL DC Fast Charger 30 kW

HJL-30DC-WxS

Connector configuration
Request a Quote

Compact Ground-Mounted DC Fast Charger for Commercial Operations

The HJL DC Fast Charger 30 kW is a reliable, ground-mounted Level 3 charging station engineered to bring efficient rapid charging to everyday commercial and fleet locations. Delivering up to 30 kW of continuous DC power, this standalone station balances high-speed energy delivery with manageable grid integration. Equipped with an interactive 7-inch touch screen and versatile user authentication systems, it offers a secure and seamless charging experience for businesses looking to adopt entry-level DC fast charging.

Key Features:

  • Dedicated 30 kW DC Output: Provides focused Level 3 DC rapid power to significantly reduce vehicle turnaround times compared to standard AC chargers.
  • Ultra-Wide Voltage Range: Features an expansive output capability spanning from 200V to 1000V DC, ensuring excellent compatibility with modern high-voltage electric vehicle architectures.
  • Interactive 7-inch Touch Screen: Outfitted with a high-contrast 7-inch user interface that clearly displays live state-of-charge parameters for intuitive driver navigation.
  • Multi-Method Authentication: Built with advanced security access supporting QR codes, RFID cards, and secure password entry to prevent unauthorized usage.
  • Rugged Heavy-Duty Build: Housed in a weather-resistant enclosure certified to IP54 standards with reliable forced-air cooling for consistent outdoor performance.
  • Premium Safety Protections: Complete with a comprehensive security grid protecting against overcurrent, overvoltage, undervoltage, short circuits, and overtemperature faults.
  • e-MOVE RO and e-Mobility RO government state aid programme compatible

Recommended Installation Sites:

  • Commercial Parking Lots & Office Hubs: Upgrade corporate parking areas to offer high-utility fast charging to clients, visitors, and executives.
  • Logistics Depots & Small Fleets: Deliver dependable rapid top-ups for localized delivery vans, company cars, and transit fleets.
  • Retail Districts & Supermarkets: Drive customer foot traffic by providing convenient 30 kW quick charging while patrons browse your store.
  • Auto Dealerships & Service Centers: Rapidly prepare demo vehicles for back-to-back test drives or charge client cars post-maintenance.
View full details

Technical Specifications

Power & Input

  • Input Grid Power Configuration: Three Phase AC system, 5-wire setup.
  • Input Nominal Voltage Range: Three Phase 380V AC plus or minus 15%.
  • Input Frequency Compatibility: 45 to 65 Hz.
  • Input Power Factor Rating: Greater than or equal to 0.99 when operating at over 50% load.

Output Performance

  • Nominal DC Power Output: 30 kW continuous power.
  • Output Voltage Range: 200V to 1000V DC.
  • Maximum System Output Current: 125A continuous.
  • Number of Charger Outlets: 1 output channel configuration.
  • Modular Series Scaling Power: Also scalable up to 60 kW, 120 kW, 180 kW, or 240 kW setups depending on architecture variant.

Connectivity & Interface

  • Station to Server Protocol: Optional protocol capability.
  • Station to CMS Gateway Interface: Optional communication gateway supporting Ethernet, 3G, 4G, or Wi-Fi.
  • User Interface Display Screen: 7-inch integrated LCD Touchscreen.
  • User Authentication Methods: QR Code, RFID Card, or Password validation.
  • Energy Consumption Metering: Integrated consumption counting units.

Safety & Physical

  • Safety Protections: Overcurrent, overvoltage, undervoltage, residual current monitoring, surge protection, current leakage block, short circuit protection, and overtemperature tracking.
  • Enclosure Protection Rating: IP54 weather-resistant protection.
  • System Thermal Cooling: Forced air cooling network.
  • Operating Temperature Range: -25C to +55C.
  • Storage Temperature Range: -40C to +70C.
  • Environmental Relative Humidity Range: 5% to 95% non-condensing room environment.
  • Installation Mounting Configurations: Ground-mounted floor installation / vertical assembly setup.
  • Physical System Asset Weight: Less than or equal to 380 kg.
  • Target 30 kW Model Identifiers: ENC-DCL030A / ANSI-DCL030A / JIS-DCL030A.
  • Industry Standards & Compliance: IEC 62196:2017, IEC 61851:2017, SAE J1772, CHAdeMO standards.
